Telefunken TK2129ST - Page 28

Item No. Description Quantity Req. Designator Remarks
26-EBP151-JCX CAP. CER 150 pF 50VDC +/-5% 1 C1501
26-EBP151-JCX CAP. CER 150 pF 50VDC +/-5% 1 C1502
40-2111SW-RMA P.C.B. REMOTE HANDSET BD 1
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J1501
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J1502
45-COS455-KY0 CERAMIC RESONATOR 455KHZ 1 X1501
49-HS45E0-00X RUBBER PAD KEYS 1
54-302000-00X FELT TAPE 15 X 4 CM 1
55-HS45EB-0HA LOWER CASE - REMOTE HANDSET 1
55-HS45ED-0HA DOOR BATT. - REMOTE HANDSET 1
55-HS45ET-1HA CASE UPPER - REMOTE HANDSET 1
56-HS45EK-1HAAA KEY KNOB (OVAL) LEFT 1
56-HS45EK-1HAAB KEY KNOB (OVAL) RIGHT 1
56-HS45EK-2HAAA KEY KNOB (OVAL) UPPER 1
56-HS45EK-2HAAB KEY KNOB (OVAL) LOWER 1
58-HS45E2-8UI INLAY REMOTE HANDSET 1
74-009022-60C POLYBAG HANDSET (9CMX22CM) 1
25-HBB470-M1X CAP. ELEC 47UF 10V +/-20% 1 C1503
67-X26968-0E2 BATT. TERMINAL (+/-) 1
67-X29681-1E2 BATTERY CONTACT SPRING (-) 1
67-X29682-0E2 BATTERY CONTACT SPRING (+) 1
08-D276SX-FBY ASS'Y - FRONT CTL BD 1
48-TAC001-XX0 TACT SWITCH 1 S1201
48-TAC001-XX0 TACT SWITCH 1 S1202
48-TAC001-XX0 TACT SWITCH 1 S1203
48-TAC001-XX0 TACT SWITCH 1 S1204
48-TAC001-XX0 TACT SWITCH 1 S1205
48-TAC001-XX0 TACT SWITCH 1 S1206
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R1205
18-CB0622-JNX RES. C.F. 6.2k OHM 1/6W +/-5% 1 R1204
18-CB0432-JNX RES. C.F. 4.3K OHM 1/6W +/-5% 1 R1203
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R1202
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R1201
46-35002H-03X HS 3P24 820 TJC3-3Y/JC25-3Y 1 P1201 TO MAIN BD. P005
08-0D276X-IRY ASS'Y - IR BD 1
11-IRR001-3X0 IR RECEIVER MODULE HK381A 1 IR001
62-346080-0HA LED HOLDER 1
46-30966H-04X HS 2468 #24 160 TJC3-4Y/SCN-4Y 1 P005
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R026
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J011
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J012
28
