Telit Wireless Solutions FN990 Series Hardware Design Guide

FN990 Family Hardware Design Guide
1VV0301752 8
Page 13 of 83
2024-05-29
CA / MIMO / EN-DC
The FN990 Family supports 2CA, 3CA, 4CA, 5CA, 6CA, and 7CA for LTE CA combinations
and EN-DC for NR FR1 configuration.
Note: Please refer to the FN990 Family CA / EN-DC list, 30691NT12001A for a
detailed list of CA and EN-DC combinations.
3.3 Target Market
The FN990 Family can be used for telematics applications where tamper-resistance,
confidentiality, integrity, and authenticity of end-user information are required, for
example:
•
Industrial equipment
•
Home network
•
Internet connectivity
3.4 Main Features
The FN990 Family of industrial-grade cellular modules features 5G Sub-6, LTE, and multi-
RAT modules together with an on-chip powerful application processor and a rich set of
interfaces.
The main functions and features are listed below:
Table 5: Main Features
Function
Features
Physical
M.2 Type 3052-S3-B
Cellular technology
FN990A28
5G: FR1(Sub 6G), Rel 16
NSA up to: 3.4Gbps on DL, 0.55Gbps on UL
SA up to: 2.5Gbps on DL, 0.9Gbps on UL
4G: CAT. 19 (1.6Gbps) on DL, CAT. 18 (211Mbps) on UL, Rel 16
3G: HSPA+ Rel9 up to 42/5.7Mbps in DL/UL
FN990A40
5G: FR1(Sub 6G), Rel 16
NSA up to: 4.1Gbps on DL, 0.55Gbps on UL
SA up to: 4.1Gbps on DL, 0.9Gbps on UL
4G: CAT. 20 (2Gbps) on DL, CAT. 18 (211Mbps) on UL, Rel 16
3G: HSPA+ Rel9 up to 42/5.7Mbps in DL/UL
Supported Bands
5G: n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/n20/n25/n26/n28/n29(SDL)/n30/n38/
n40/n41/n48/n66/n71/n75(SDL)/n76(SDL)/n77/n78/n79
4G: B1/B2(B25)/B3/B4(B66)/B26(B5,B18,B19)/B7/B8/B12(B17)/B13/B14/B20/B28/
B29(SDL)/B30/ B32(SDL)/B34/B38/B39/B40/B41/B42/B43/B46(SDL)/B48/B71
3G: B1/B2/B4/B5(B6,B19)/B8
1Tx / 4Rx (4x4 DL
MIMO)
5G: n1/n2/n3/n7/n25/n30/n38/n40/n41/n48/n66/n75/n77/n78/n79
4G: B1/B2/B3/B4/B7/B25/B30/B32/B34/B38/B39/B40/B41/B42/B43/B48/B66
