LE910Cx mPCIe Hardware Design Guide
1VV0301510 Rev. 13 Page 66 of 73 2021-07-07
Not Subject to NDA
Mode
Freq. Tx (MHz)
Freq. Rx (MHz)
Channels
Tx-Rx Offset
LTE 900 – B8
880 ~ 915 925 ~ 960
Tx: 21450 ~ 21799
Rx: 3450 ~ 3799
45 MHz
LTE 1800 – B9
1749.9 ~ 1784.9 1844.9 ~ 1879.9
Tx: 21800 ~ 2149
Rx: 3800 ~ 4149
95 MHz
LTE AWS+ – B10
1710 ~ 1770 2110 ~ 2170
Tx: 22150 ~ 22749
Rx: 4150 ~ 4749
400 MHz
LTE 700a – B12
699 ~ 716 729 ~ 746
Tx : 23010 ~ 23179
Rx : 5010 ~ 5179
30 MHz
LTE 700c – B13
777 ~ 787 746 ~ 756
Tx : 27210 ~ 27659
Rx : 9210 ~ 9659
-31 MHz
LTE 700PS – B14
788 ~ 798 758 ~ 768
Tx: 23280 ~ 23379
Rx: 5280 ~ 5379
-30 MHz
LTE 700b – B17
704 ~ 716 734 ~ 746
Tx: 23730 ~ 23849
Rx: 5730 ~ 5849
30 MHz
LTE 800 – B19
830 ~ 845 875 ~ 890
Tx: 24000 ~ 24149
Rx: 6000 ~ 6149
45 MHz
LTE 800 – B20
832 ~ 862 791 ~ 821
Tx: 24150 ~ 24449
Rx: 6150 ~ 6449
-41 MHz
LTE 1500 – B21
1447.9 ~ 1462.9 1495.9 ~ 1510.9
Tx: 24450 ~ 24599
Rx: 6450 ~ 6599
48 MHz
LTE 1900+ – B25
1930 ~ 1995 1850 ~ 1915
Tx: 26040 ~ 26689
Rx: 8040 ~ 8689
80 MHz
LTE 850+ – B26
814 ~ 849 859 ~ 894
Tx: 26690 ~ 27039
Rx: 8690 ~ 9039
45 MHz
LTE 700 – B28A
703 ~ 733 758 ~ 788
Tx: 27210 ~ 27510
Rx: 9210 ~ 9510
55 MHz
LTE 700 – B28
703 ~ 748 758 ~ 803
Tx : 27210 ~ 27659
Rx : 9210 ~ 9659
45 MHz
LTE AWS-3 – B66
1710 ~ 1780 2210 ~ 2200
Tx: 131972-132671
Rx: 66436-67335
400 MHz
LTE600 – B71
663 ~ 698 617 ~ 652
Tx: 133122-133471
Rx: 68568-68935
46 MHz
LTE TDD 2600 – B38
2570 ~ 2620 2570 ~ 2620
Tx: 37750 ~ 38250
Rx: 37750 ~ 38250
0 MHz
LTE TDD 1900 – B39
1880 ~ 1920 1880 ~ 1920
Tx: 38250 ~ 38650
Rx: 38250 ~ 38650
0 MHz
LTE TDD 2300 – B40
2300 ~ 2400 2300 ~ 2400
Tx: 38650 ~ 39650
Rx: 38650 ~ 39650
0 MHz
LTE TDD 2500 – B41M
2555 ~ 2655 2555 ~ 2655
Tx: 40265 ~ 41215
Rx: 40265 ~ 41215
0 MHz
Table 28: RF Bands Characteristics
