1.
Open the lens cover (1).
2.
Press the ON/OFF (9) button briefly to turn on the device.
3.
Adjust the eyepiece diopter ring (13) until the symbols in the display
are sharp.
4.
Rotate the lens focus ring (3) to focus on the object being observed.
5.
To change the magnification, turn the digital zoom adjustment ring (4).
6.
Enter the main menu with a long press of the MENU (11) button and
select the desired calibration mode: manual (M), semi-automatic (SA)
or automatic (A).
7.
Calibrate the image by briefly pressing the ON/OFF (9) button (if the
SA or M calibration mode has been selected). Close the lens cover
when calibrating manually.
8.
Activate the quick menu by briefly pressing theMENU (11) button to
adjust the brightness and contrast of the display and select the desired
amplification level (“Normal” , “High” , “Ultra”
)(for more details see the Quick Menu section).
9.
Activate the smoothing filter in the main menu to improve the
image as the amplification level increases.
10.
Select one of the colour palettes in the main menu (for more details
see theColour Modes section).
