Telos LRF - Page 5

1.
Screw the tripod adapter(2)onto the tripod mounting plate until it
stops.
2.
Attach the mounting plate (3) to the tripod.
3.
Install the Telos LRF (1) device into the tripod adapter(2)so that the
rangefinder lens aligns with the hole on the front of the tripod adapter
(2).
4.
Turn the handle of the tripod adapter (2) to position .
5.
Level the Telos LRF (1) horizontally and vertically using the tripod
mounting plate (3).
Notes:
The tripod adapter is not designed to be mounted on a vehicle.
When adapter is installed, the user can move the rear part of the device
up.
When the adapter knob is moved to the closed position , the
horizontal direction of the device may shift slightly.
