Tenda V300 - To Set up WAN Service for Ethernet Interface

34
4.2.3 To Set up WAN Service for Ethernet Interface
Log in to the web UI, choose Advanced > Advanced Setup > WAN Service to enter the following page.
Step 1 Click Add.
Step 2 Select the interface you create in Layer2 Interface, interface atm0/(0_1_35) here.
Step 3 Click Next.
Step 4 Select a WAN service type according to the instructions in the table below. Here take PPPoE as an
example.
Connection Type
Description
PPP over Ethernet (PPPoE)
Select thus type if your internet service provider (ISP) provides a user
name and password to you for internet access.
IP over Ethernet
Dynamic IP
Select thus type if your ISP does not provide any parameters to you for
internet access.
