We make every effort to ensure that all units ship complete and arrive undamaged. However, should your
unit contain missing or damaged parts, replacements may be obtained directly from us. To obtain proper
replacement parts, follow the instructions below, or fill out the form at www.tennsco.com/partsorder.html.
●●
●●
●
●●
●●
●
●●
●●
●
●●
●●
●
●●
●●
●
●●
●●
●
●●
●●
●
●●
●●
●
TO OBTAIN PROPER REPLACEMENT PARTS, PLEASE PROVIDE THE FOLLOWING INFORMATION:
Model Number (J2478SU) Purchase Date
Description of part(s) needed and part Your company name
number(s) as shown in Parts List (above) Contact person's name
Color (i.e. Medium Grey, etc.) Who the product was purchased from
Was item missing, or was it damaged?
Tennsco Corp., P.O. Box 1888, Dickson, TN 37056-1888 Customer Service: (866) 446-8686 Fax: (866) 445-7260
If requesting parts by telephone, ask for customer service and have as much of the above information ready as possible.
Shelf Adjustment
1. Using a flat-head screwdriver,
gently pull the locking tab
away from the hole in the
shelf edge. This will allow the
shelf to be released and lifted
from the tab.
2. Place the shelf at the desired
level.
3. Insert the shelf edges into the
tabs at the new location. Be
sure that the shelf is securely
fitted into the tabs at all points
of contact.
View from
beneath shelf
Shelf 306
Door (left) 056LD
Door (right) 056RD
Hinge pin 944HP
PART DESCRIPTION
REPLACEMENT PARTS
PART NO.
For Storage Cabinet For Locking Handle
PART DESCRIPTION PART NO.
Lock bar set 043LB
Locking Handle w/keys and hardware 043LH
Dummy Handle 043DH
Locking Cam* 944LC
Cam Retainer* 944CR
Lock bar guide insert* 944GI
*Included in Locking Handle w/keys and hardware (part no. 944LH). May be ordered alone or as part of the full hardware set.
Leveling the Cabinet
1. If cabinet doors don't
easily open and close,
your unit likely needs
leveling.
2. Open the cabinet doors
and locate the leveling
hole on each side of the
cabinet base.
3. Insert a flathead screw-
driver into each leveling
hole, and turn the screw
until the leveler is at the
desired position.
4. If cabinet is properly
leveled, doors should
open and close freely.
Insert screwdriver
through hole (above) to
adjust leveler (below).
View from underside
of cabinet
