Terex Genie GS84D-401 User Manual

June 2021 Service and Repair Manual
Deutz TD 2.2 L3 Engine Fault Codes
Part No. 1306587GT GS
™
-84 • GS
™
-90 141
DTC = Diagnostic Trouble Code
FMI = Failure Mode Identifier
SPN = Suspect Parameter Number
DTC
SPN
FMI
Description
1000
98
2
Engine oil level sensor internal
error. Sensor reports error.
Open/short transducer.
1001
98
31
Engine oil level out of range. Level
low, high, foaming.
1002
98
31
Oil sensor voltage out of range.
<8,5V
±0,5V; >16,5V ±0,5V.
1003
98
2
Oil sensor invalid sensor status.
1004
98
31
Oil se
nsor temperature out of
range.
1005
98
14
Oil sensor is broken or
disconnected.
1021
100
3
Oil pressure voltage above normal
or shorted to high.
1022
100
4
Oil
pressure voltage below normal
or shorted to low.
1025
100
1
Low oil pressure. Warning
thresh
old exceeded.
1026
100
1
Low oil pressure. Shut off threshold
exceeded.
1043
107
0
Air filter differential pressure. Air
filter clogged.
1071
411
2
Engine
exhaust gas recirculation.
Pressure does not change
between engine operating points.
1072
411
0
E
ngine exhaust gas recirculation.
Pressure above normal operational
range.
1073
411
1
Engine exhaust gas recirculation.
Pressure below normal
operational
range.
1074
411
2
Engine exhaust gas recirculation.
Negative measured differential
pressure.
1075
41
1
2
Engine exhaust gas recirculation.
Positive measured differential
pressure.
DTC
SPN
FMI
Description
1077
411
3
Engine exhaust gas
recirculation.
Signal value above maximum limit.
1078
411
4
Engine exhaust gas recirculation.
Signal value below ma
ximum limit.
1079
108
0
Ambient air pressure sensor above
normal operational range.
1080
108
1
Ambient air pressure sensor below
normal op
erational range.
1081
108
15
Fault check max signal range
violated for ambient air pressure
sensor.
1082
108
17
Fa
ult check min signal range
violated for ambient air pressure
sensor.
1083
108
2
Ambient air pressure sensor error
by component self
diagnosis.
1084
3720
0
DPF ash load above normal
operational range.
1086
3734
0
DPF soot load exceeded. Remove
filter lev
el.
1087
4781
14
DPF soot load exceeded shut off
level.
1088
4781
0
DPF soot load exceeded warning
level.
1089
4781
16
DPF. Too
much standstill time in
short time interval.
1090
10156
0
DPF. The standstill
-regeneration
mode time exceeds the short
-limit.
1091
3735
16
DPF. Standstill required and no
successful standstill longer than
escalation threshold. Moderately
severe.
1092
37
35
0
DPF. Standstill required and no
successful standstill longer than
escalation threshold. Most severe.
1093
4766
1
DOC. R
egeneration temperature in
standstill main phase not reached.
1102
171
2
Ambient air temperature shows a
deviation from
expected value at
cold start conditions.
