Ford MSG-425 Engine Fault Codes
154 GS
™
-84 • GS
™
-90 Part No. 1306587GT
Code
Description
1173
Megajector comm lost
1174
Megajector voltage supply high
1175
Megajector voltage supply low
1176
Megajector internal actuator fault detection
1177
Megajector internal circuitry fault detection
1178
Megajector internal comm fault detection
1311
M
isfire detected
1312
Misfire detected
1313
Misfire detected
1314
Misfire detected
1315
Misfire detected
1316
Misfire detected
1317
Misfire detected
1318
Misfire detected
1511
AUX analog PU
1 high
1512
AUX analog PU
1 low
1513
AUX analog P
U2 high
1514
AUX analog PU
2 low
1515
AUX
analog PD1 high
1516
AUX analog PD
1 low
1517
AUX analog PU
3 high
1518
AUX analog PU
3 low
1521
CHT higher than expected 1
1522
CHT higher than expected 2
1531
IVS/Brake/Trans
-Park interlock failure
1541
AUX analog PUD
1 high
1542
AUX
analog PUD1 low
1543
AUX analog PUD
2 high
1544
AUX analog PUD
2 low
1545
AUX analog PUD
3 high
Code
Description
1551
AUX DIG
1 high
1552
AUX DIG
1 low
1553
AUX DIG
2 high
1554
AUX DIG
2 low
1555
AUX DIG
3 high
1556
AUX DIG
3 low
1561
AUX analog PD
2 high
1562
AUX analog PD
2 low
1563
AUX analog PD
3 high
1564
AUX analog PD
3 low
1611
5VE 1/
2 simultaneous out of range
1612
RTI
1 loss
1613
RTI
2 loss
1614
RTI
3 loss
1615
A/D loss
1616
Invali
d interrupt
1621
Rx Inactive
1622
Rx Noise
1623
Invalid Packet Format
1624
Shutdown Request
1625
Shutdown Request
1626
CAN Tx failure
1627
CAN Rx failure
1628
CAN addresss conflict failure
For further engine fault code troubleshooting and
diagnostic information, refer to the Ford MSG-425
EFI Diagnostic Manual (EDI part number
1080030).
Ford MSG
-425 EFI Diagnostic Manual
Genie part number
162067
