Terex Genie GS84D-401 User Manual

Service and Repair Manual June 2021
Scissor Components
34 GS
™
-84 • GS
™
-90 Part No. 1306587GT
4 Place a 12 inch / 30 cm block under the
center of the scissor arm pair. Lower the
scissor arm pair onto the block.
5 Remove the external snap rings from both
center pivot pins.
6 Use a soft metal drift to remove both center
pins.
7 Carefully separate the scissor arm pair.
Crushing hazard. The scissor
arms could become unbalanced
and fall if not properly supported
by the overhead
cranes.
