PLUGGING IN
CAUTION: Always inspect the GB AC Adapter
for damage prior to each use.
1
With your key nearby, use the touchscreen or other
method to open the charge port on your Tesla
vehicle.
2
Attach the GB AC Adapter to the end of the
charger’s charge cable and use the latch to lock the
adapter into place.
3
Plug the GB AC Adapter into your Tesla vehicle and
wait for the vehicle to engage a latch that holds the
adapter in place.
4
Follow the instructions on the GB AC charger to
start the charging session.
NOTES:
• Steps 2 and 3 can be done in reverse order.
• The operation of the GB AC charger will vary
depending on the charger’s manufacturer. For
details, refer to the GB AC charger’s instructions.
• Check the instrument panel or the touchscreen to
confirm that charging is in progress.
UNPLUGGING
When charging is complete:
1
Follow the instructions on the charger to stop the
charging session.
2
Press and hold the button on the charger’s charge
cable, wait for the vehicle’s latch to retract, then
pull the adapter out of the charge port.
3
Push the charge port door closed.
4
Unplug the GB AC Adapter from the charger and
store it in an appropriate location.
