Technical data
26 Testboy
®
TB 313
DEUTSCH
DEUTSCH
DEUTSCH
Only use the specified batteries!
Do not dispose of batteries in normal household rubbish! Observe statutory regula-
tions pertaining to disposal!
Changing the fuse
When changing the fuse, remove the measurement leads from the device and remove the screws
on the rear of the device (two at the bottom, one at the top). Carefully remove the rear of the
housing and replace the fuse with fuse of the same type (Fuse F 10 A / 1000 V). Replace screws
and screw tight.
The F200 mA fuse is self-resetting and therefore maintenance free.
Only use the specified fuse!
Technical data
The accuracy relates to 1 year used in temperatures between 18 °C – 28 °C and 75% relative
humidity. Further calibration is also offered.
Max. voltage between the connection socket and ground:
600 V AC / DC
Fuses
F 200 mA self-resetting (maintenance free)
F 10 A 1000 V quick-blow
Max. operating height:
2000 m above MSL
Height of display:
37 mm LCD
Display
Max. 1999 (3½ )
Polarity indicator
Automatic
Overrange indicator:
"1" is displayed
Sampling rate
Approx. 0.4 sec.
Low battery status:
Battery symbol is displayed
Power supply
1 × 9 V block battery
Operating temperature
0 °C to 40 °C
Storage temperature
-10 °C to 50 °C
Dimensions
191 × 82 × 37 mm (without holster)
200 × 89 × 38 mm (with holster)
Weight
280 g incl. battery
Category
CAT III 600 V
