Testboy Testavit Schuki 3 LCD - Technical Specifications

Operation
24 Testavit
®
Schuki
®
3 LCD
Measurement category IV:
Measurement category IV is applicable to test and measuring
circuits connected at the source of the building’s low-voltage
mains installation. Typical short-circuit current is >> 50kA.
Read the instruction before use. If the equipment is used in a
manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
All parts of the device are not allowed to be changed or
replaced, other than authorized by the manufacturer or his
agent.
For cleaning the unit, use a dry cloth.
Technical data
Voltage range
230 V AC, 50 Hz
Power supply
by test object, max. 3 mA
Degree of protection
IP 40
Over-voltage category
CAT II 300 V
Temperature range
0° ~ +50°C
Testing standard
IEC/EN 61010-1
(DIN VDE 0411)
