TestEquity 115A - Detailed Parts Lists - Electrical and Refrigeration; Detailed Parts Lists - General Hardware

Chapter 8 – Maintenance
Page 8-10 TestEquity 115A Temperature Chamber
Major Electrical Parts
Description
Mfr
Mfr Part No.
Ref #
Part #
Qty
UOM
Line Cord, 12/3, NEMA 5-20P
Intl. Config.
80560
--
200205
1
ea
Audible Alarm
Floyd Bell
MC-09-201-Q
AL1
200005
1
ea
Arc Suppressor
ITW Paktron
104MACQRL150
AS1
200296
1
ea
Relay, DPDT, 30A, 120VAC
Magnecraft
92S11A22D-120
C1
200258
1
ea
Contactor, 1P, 30A
Hartland Controls
HCC-1XT02AA
C2-3
200237
2
ea
Interference Suppression Capacitor
STK Electronics
MPX100K250SP
CP1
280206
1
ea
Fuse, 3/10A
Bussman
MDL-3/10
F1
200130
1
ea
Circulator Motor Kit (w/fan blade)
CUSTOM
100578
FM1
100578
1
ea
Heat Limiter Assembly
CUSTOM
222253
HL
222253
1
ea
Heater, Air
CUSTOM
200199
HT1
200199
1
ea
Lamp, 15W, E14 Base
Philips
T22, 125-130V, 15W, E14
LT1
200203
1
ea
Indicator, Panel, 125V Neon
SoLiCo
1550-4-20-12120
PL1, 2
200025
2
ea
Resistor, 1kΩ, 25W
Vishay
RH0251K000FE02
R1
200295
1
ea
Solid State Relay, 10A, 24VDC In
Omron
G3NE-210T-US DC24
SSR1
200177
1
ea
Solid State Relay, 5A, 5-24VDC In
Omron
G3NA-205B-DC5-24
SSR2, 3
200032
2
ea
Switch, SPST, Rocker
Carlingswitch
LRA211-RA-B/125N
SW1, 3
200023
2
ea
Switch, ON-OFF-ON
Carlingswitch
RC911-RA-B-0-N-XLR1
SW2
200275
1
ea
F4T Temperature Controller
Watlow
F4T1L2EAA2E1017
TCR1
222510
1
ea
F4 Temperature Controller (alternate)
Watlow
F4SH-CKA0-01AE
TCR1
200001
1
ea
High/Low Limit Controller
Watlow
PM6L1AJ-AAAABBS
TCR2
200301
1
ea
Timing Module
Airotronics
THCU30SC
TM1
200287
1
ea
Major Refrigeration Parts
Description
Mfr
Mfr Part No.
Ref #
Part #
Qty
UOM
Accumulator
CUSTOM
100345
4
100345
1
ea
Cap. Tube, 0.050
J/B or equiv.
TC-50 or equiv.
11
100019
120
in
Cap. Tube, 0.050
J/B or equiv.
TC-42 or equiv.
12
100019
15
in
Cap. Tube, 0.042
J/B or equiv.
TC-42 or equiv.
13
100340
60
in
Cascade Condenser
CUSTOM
180572
16
180572
1
ea
Compressor (LS)
Tecumseh
AFE13C3E-IAA-201
1
383233
1
ea
Condensing Unit (HS)
Tecumseh
AE2415Z-AA1A
2
383232
1
ea
Desuperheater Coil
CUSTOM
100325
3
100325
1
ea
Evaporator Coil
CUSTOM
180220
17
180220
1
ea
Expansion Tank
CUSTOM
100346
5
100346
1
ea
Expansion Valve
Danfoss
068U2284
15
180395
1
ea
Filter Drier
Danfoss
023Z5048
14A, B
100524
2
ea
Oil Separator
Temprite
900
18
100536
1
ea
Orifice for 180395
Danfoss
068U1031
22
180396
1
ea
Pressure Control, HS HPCO
Johnson Controls
P20DB-1D
8 (PS2)
100341
1
ea
Pressure Control, LS HP Limit
Johnson Controls
P20EA-1D
7 (PS1)
100342
1
ea
Solenoid Valve
Sporlan
E3S130, 3/8 X 3/8 ODF
6 (SV1)
100010
1
ea
Solenoid Valve
Sporlan
E3S120, 1/4 X 1/4 ODF
20 (SV2)
100310
1
ea
Solenoid Valve Coil
Sporlan
MKC-1-120/50-60
21 (SV1, 2)
100011
2
ea
General Parts
Description
Mfr
Mfr Part No.
Ref #
Part #
Qty
UOM
Caster, Fixed (for 115A-F)
Trio Pines
2521-02P
-
300610
2
ea
Caster, Swivel (for 115A-F)
Trio Pines
2520-02P-SB
-
300609
2
ea
Door Gasket, Inner
CUSTOM
300593
-
300593
1
ea
Door Gasket, Outer
CUSTOM
300594
-
300594
1
ea
Door Latch, Chamber Workspace
Southco
A7-10-301-20
-
300216
1
ea
Port Plug, Silicone Foam, 3"
CUSTOM
300373
-
300373
2
ea
Shelf
CUSTOM
TE-1151
-
TE-1151
1
ea
Viewing Window
CUSTOM
300691
-
300691
1
ea
