3 0970 8701 en 01 V01.00 en
Selecting the colour palette
testo 870-2: function only available if the Image type infrared has been
selected.
1 - Move the Joystick (4) up/down to toggle between the colour
palettes.
Selecting the image type (infrared image, real image) (only testo 870-2)
1 - Select the Image type function. For how to do this, see Navi-
gating the menu.
The image type switches automatically from infrared image to real
image and vice versa.
Setting the scale
testo 870-2: function only available if the Image type infrared has been
selected.
Automatic scaling adjusts the scale continuously to the relevant
measuring values, and the colour assigned to a measuring value
changes.
With manual scaling, fixed limit values are defined, and the colour
assigned to a measuring value is fixed (important for visual image
comparisons).
Scaling influences the way the infrared image is shown on the dis-
play but does not affect the recorded measuring values.
1 - Select the Scale function. For how to do this, see Navigating the
menu.
2 - Move the Joystick (4) left/right until Auto is selected and then
press OK (4).
Automatic scaling is activated. is shown at the bottom right of
the display.
2.1
- Move the Joystick (4) left/right until (lower limit value) is selected.
- Move the Joystick (4) up/down to set the value and then press OK
(4).
2.2
- Move the Joystick (4) left/right until (lower limit value) and (up-
per limit value) are selected.
- Move the Joystick (4) up/down to set the values and then press OK
(4).
2.3
- Move the Joystick (4) left/right until (upper limit value) is selected.
- Move the Joystick (4) up/down to set the value and then press OK
(4).
Manual scaling is activated. is shown at the bottom right of the
display.
Assigning the quick select button
- The quick select button (5) is a additional navigation option,
which you can use to call up functions a the touch of a button.
1 - Move the Joystick (4) right to select the Assign button function.
2 - Move the Joystick (4) up/down to select the required function,
then press OK (4).
The icon for the selected function is shown at the bottom right of
the display.
3
- Press (5) to call up the function.
testo 870
Brief instructions
www.testo.com
These brief instructions describe the basic operating steps. Please
refer to the instruction manual to find out how to handle the product
safely and for detailed information.
testo 870
brief
instructions
testo 870
instruction
manual
