Connections and Operational Controls
5
2
64
1 On/Off button
2 Volume control
3 Charge contacts
4 Connector for power adaptor (DC 10V/2.5A )
5 Reset button
6 USB port (master, type A)
1
3
Controller
Charger
1 Charge contacts
2 Connector for power adaptor (DC 10V/2.5A )
