MOUNTING MRC+
These units are designed to stand on a flat surface. If the unit is to be wall mounted the following kits are
available.
KIT
MRC+ 15-80
MRC+ 90-180
Mounting Bracket
55021100
55021101
Whether floor or wall mounted, it is essential that the mounting surface is capable of supporting the unit
weight. Leave space around the unit for air circulation and access for installation and maintenance.
Dimensions in mm.
DIMENSIONS & WEIGHTS MRC+
MRC+ 15-100 (Dimensions in mm.)
MODEL
A
B
C
D
E
F
G
H
Weight (kg)
1 Ph
3 Ph
MRC+ 15
900
300
560
525
185
60
295
275
46
-
MRC+ 20
900
300
560
525
185
60
295
275
47
-
MRC+ 30
900
300
560
525
185
60
295
275
48
48
MRC+ 40
900
300
560
525
185
60
295
275
53
53
MRC+ 45
1000
350
660
495
250
60
345
325
61
-
MRC+ 50
1000
350
660
495
250
60
345
325
64
64
MRC+ 60
1000
350
660
495
250
60
345
325
65
65
MRC+ 80
1000
350
660
495
250
60
345
325
66
66
MRC+ 90
1000
350
760
495
250
70
345
325
76
76
MRC+ 100
1000
350
760
495
250
70
345
325
81
81
1500 min air off
100 min
100 min
600 min
MOUNTING HOLES
