Add Using Doubleword Addressing Mode ADDAD
3-51 Instruction SetSPRU733
Instruction Type Single-cycle
Delay Slots 0
Functional Unit
Latency
1
See Also ADD, ADDAB, ADDAH, ADDAW
Example
ADDAD .D1 A1,A2,A3
Before instruction 1 cycle after instruction
A1
0000 1234h
4660 A1 0000 1234h 4660
A2 0000 0002h 2 A2 0000 0002h 2
A3 xxxx xxxxh A3 0000 1244h 4676
