AND Bitwise AND
3-68 Instruction Set SPRU733
Pipeline
Stage
E1
Read src1, src2
Written dst
Unit in use
.L or .S
Instruction Type Single-cycle
Delay Slots 0
See Also OR, XOR
Example 1
AND .L1X A1,B1,A2
Before instruction 1 cycle after instruction
A1
F7A1 302Ah
A1 F7A1 302Ah
A2 xxxx xxxxh A2 02A0 2020h
B1 02B6 E724h B1 02B6 E724h
Example 2 AND .L1 15,A1,A3
Before instruction 1 cycle after instruction
A1
32E4 6936h
A1 32E4 6936h
A3 xxxx xxxxh A3 0000 0006h
