Compare for Less Than, Signed Integers CMPLT
3-97 Instruction SetSPRU733
Example 1 CMPLT .L1 A1,A2,A3
Before instruction 1 cycle after instruction
A1
0000 07E2h
2018 A1 0000 07E2h
A2 0000 0F6Bh 3947 A2 0000 0F6Bh
A3 xxxx xxxxh A3 0000 0001h true
Example 2 CMPLT .L1 A1,A2,A3
Before instruction 1 cycle after instruction
A1
FFFF FED6h
−298 A1 FFFF FED6h
A2 0000 000Ch 12 A2 0000 000Ch
A3 xxxx xxxxh A3 0000 0001h true
Example 3 CMPLT .L1 9,A1,A2
Before instruction 1 cycle after instruction
A1
0000 0005h
5 A1 0000 0005h
A2 xxxx xxxxh A2 0000 0000h false
