Load Halfword From Memory With a 5-Bit Unsigned Constant Offset or Register Offset LDH(U)
3-133 Instruction SetSPRU733
Example LDH .D1 *++A4[A1],A8
Before LDH 1 cycle after LDH 5 cycles after LDH
A1
0000 0002h
A1 0000 0002h A1 0000 0002h
A4 0000 0020h A4 0000 0024h A4 0000 0024h
A8 1103 51FFh A8 1103 51FFh A8 FFFF A21Fh
AMR 0000 0000h AMR 0000 0000h AMR 0000 0000h
mem 24h A21Fh mem 24h A21Fh mem 24h
A21Fh
