MPYID Multiply 32-Bit x 32-Bit Into 64-Bit Result
3-160 Instruction Set SPRU733
Functional Unit
Latency
4
See Also MPYI
Example
MPYID .M1 A1,A2,A5:A4
Before instruction 10 cycles after instruction
A1
0034 5678h
3430008 A1 0034 5678h 3430008
A2 0011 2765h 1124197 A2 0011 2765h 1124197
A5:A4 xxxx xxxxh xxxx xxxxh A5:A4 0000 0381h CBCA 6558h 3856004703576
