Normalize Integer NORM
3-193 Instruction SetSPRU733
Execution if (cond) norm(src) → dst
else nop
Pipeline
Stage
E1
Read src2
Written dst
Unit in use
.L
Instruction Type Single-cycle
Delay Slots 0
Example 1
NORM .L1 A1,A2
Before instruction 1 cycle after instruction
A1
02A3 469Fh
A1 02A3 469Fh
A2 xxxx xxxxh A2 0000 0005h 5
Example 2 NORM .L1 A1,A2
Before instruction 1 cycle after instruction
A1
FFFF F25Ah
A1 FFFF F25Ah
A2 xxxx xxxxh A2 0000 0013h 19
Pipeline
