Store Byte to Memory With a 15-Bit Unsigned Constant Offset STB
3-239 Instruction SetSPRU733
Pipeline
Stage
E1
Read B14/B15, src
Written
Unit in use
.D2
Instruction Type Store
Delay Slots 0
See Also STH, STW
Example
STB .D2 B1,*+B14[40]
Before
instruction
1 cycle after
instruction
3 cycles after
instruction
B1
1234 5678h
B1 1234 5678h B1 1234 5678h
B14 0000 1000h B14 0000 1000h B14 0000 1000h
mem 1028h 42h mem 1028h 42h mem 1028h 78h
Pipeline
