Bitwise Exclusive OR XOR
3-271 Instruction SetSPRU733
Execution if (cond) src1 XOR src2 → dst
else nop
Pipeline
Stage
E1
Read src1, src2
Written dst
Unit in use
.L or .S
Instruction Type Single-cycle
Delay Slots 0
See Also AND, OR
Example 1
XOR .S1 A3, A4, A5
Before instruction 1 cycle after instruction
A3
0721 325Ah
A3 0721 325Ah
A4 0019 0F12h A4 0019 0F12h
A5 xxxx xxxxh A5 0738 3D48h
Example 2 XOR .L2 B1, 0dh, B8
Before instruction 1 cycle after instruction
B1
0000 1023h
B1 0000 1023h
B8 xxxx xxxxh B8 0000 102Eh
Pipeline
