Absolute Value With Saturation ABS
3-39 Instruction SetSPRU733
Instruction Type Single-cycle
Delay Slots 0
See Also ABSDP, ABSSP
Example 1
ABS .L1 A1,A5
Before instruction 1 cycle after instruction
A1
8000 4E3Dh
−2147463619 A1 8000 4E3Dh −2147463619
A5 xxxx xxxxh A5 7FFF B1C3h 2147463619
Example 2 ABS .L1 A1,A5
Before instruction 1 cycle after instruction
A1
3FF6 0010h
1073086480 A1 3FF6 0010h 1073086480
A5 xxxx xxxxh A5 3FF6 0010h 1073086480
