THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page G-10
10015775 Service Parts Manual
ELECTRICAL
1 651698G03 Front Grille with LED Headlight Assembly (Hi/Low) (Includes Items 2 - 4) ...... 1
2 651411G03 LED Headlight ........................................................................................... 2
3 648564 Front Grille with Lights............................................................................... 1
4 651437 Lens Cover ................................................................................................ 2
5
6
7 71597G01 Self Threading Nut ........................................................................................... 9
8 71781G02 Vinyl Tape......................................................................................................... 2
9 619102 Turn Signal Bulb............................................................................................... 1
10
11
12
13 10013736 Jumper Harness, Taillight Halogen (Not Illustrated)......................................... 1
14
15
16
17
18
19 71364G02 "J" Type Nut, #8 ............................................................................................... 4
20 71425G01 Tapping Screw, #8 - 18 X 3/4" Lg..................................................................... 4
21
22 655170 Taillight Assembly (Driver Side) (Includes Items 24, 26 - 28).......................... 1
23 655171 Taillight Assembly (Passenger Side) (Includes Items 25 - 28) ........................ 1
24 74371G01 Taillight Bezel (Driver Side) ....................................................................... 1
25 74371G02 Taillight Bezel (Passenger Side)................................................................ 1
26 00513G4 Pan Head Phillips Screw, #8 - 18 x 3/4" Lg ............................................... 2
27 22288G1 Taillight Assembly. ..................................................................................... 1
28 14601G11 Rivet (Aluminum), 3/16" X 9/16" ................................................................ 2
To Next Page
