When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page A-4
Service Parts Manual
ACCELERATOR
31 25799G03 ACCELERATOR PEDAL ASSEMBLY (INCLUDES ITEMS 32 - 35)......... 1
32 652824 ACCELERATOR PEDAL.................................................................... 1
33
34 27512G01 ACCELERATOR PEDAL PAD............................................................ 1
35 16409G1 OVAL RIVET, 3/8" X 15/32" LG.......................................................... 6
36
37 17838G1 NYLON BUSHING.................................................................................... 3
38 74432G01 PEDAL PIVOT PIN, 4.87" LG ................................................................... 1
39 12064G6 PUSH NUT, 9/32" I.D................................................................................ 1
40
41 10386G3 CLEVIS PIN, 5/16" X 13/16" LG ............................................................... 1
42
43 10387G3 COTTER PIN, 3/32" X 3/4" LG................................................................. 1
44
45 00715G2 HEX HEAD FLANGE BOLT, 5/16" - 18 X .8" LG............................................. 4
46 70135G01 PEDAL PIVOT COVER................................................................................... 1
