Page C-3
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 628017 IP ASSEMBLY (INCLUDES ITEMS 2 - 6)........................................................ 1
2 628010 IP ASSEMBLY WITH COMPARTMENT.................................................... 1
3 641632G01 BALL HOLDER (DRIVER SIDE) ............................................................... 1
4 641632G02 BALL HOLDER (PASSENGER SIDE)....................................................... 1
5 00614G3 PAN HEAD PHILLIPS TAPPING SCREW, #8 - 15 X 3/8" LG .................. 4
6 71364G02 ’J’ TYPE SPEED NUT, #8 - 15 X .198" LG................................................ 5
7
8 628023 CUP HOLDER ................................................................................................. 1
9 71115G01 TRIM................................................................................................................ 2
10 71055G01 RIVET, 3/16" X .985" DIA................................................................................. 11
11 608290 PAN HEAD PHILLIPS TAPPING SCREW, #10 - 16 X 3/4" LG ....................... 5
12 625240 SAFETY LABEL............................................................................................... 1
13
14
15
16 619730G0XX COWL (see COLOR CODES in HOW TO USE section)................................. 1
17 71055G01 RIVET, 3/16" X .985" DIA................................................................................. 7
18 10570G11 RIVET (SS), 3/16" X .70"................................................................................. 2
19
20 16816G2 RATCHET RIVET, .25" X .887"........................................................................ 2
21
22 619730G1XX COWL WITH OPENINGS FOR LIGHTS
(see COLOR CODES in HOW TO USE section)............................................. 1
23
24
25 00438G6 HEX HEAD BOLT (WITH TOP), 5/16" - 18 X 3/4" LG ..................................... 2
26 00571G2 FLAT WASHER, 5/16" ..................................................................................... 2
27 71781G02 VINYL TAPE .................................................................................................... 2
28 71056G01 TRUSS HEAD MACHINE SCREW (WITHOUT TOP), 5/16" - 18 X .62" LG ... 4
29 00570G2 FLAT WASHER, 5/16" ..................................................................................... 4
30
31 624607 FRONT SHIELD .............................................................................................. 1
BODY - FRONT
