Page #42 background image
Page D-5
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 70612G02 BRAKE PEDAL ASSEMBLY (WITHOUT BRAKE LIGHTS)
(INCLUDES ITEMS 2 - 10).............................................................................. 1
2 70681G01 TORSION SPRING................................................................................... 2
3 70682G01 PIVOT PIN ................................................................................................ 1
4 658825 PUSHNUT, 5/16"....................................................................................... 2
5 652251G03 BRAKE PEDAL ......................................................................................... 1
6 652253G03 PARK BRAKE PEDAL............................................................................... 1
7
8 70257G01 SERVICE BRAKE PAD ............................................................................. 1
9 70256G01 PARK BRAKE PEDAL PAD....................................................................... 1
10 16409G1 OVAL RIVET, 3/16" X 7/16" LG................................................................. 9
11
12 70582G01 SHOULDER BOLT (SS), 3/8" - 16 X 4" LG ..................................................... 1
13 70581G01 ACETAL FLANGED BUSHING........................................................................ 2
14 70676G01 TORSION SPRING ......................................................................................... 1
15 00643G1 FLAT WASHER, 3/8" ....................................................................................... 1
16 11098G5 LOCK NUT, 3/8" - 16 ....................................................................................... 1
17
18 01038G01 SWAGEFORM SCREW, 1/4" - 20 (NOT ILLUSTRATED)............................... 1
19
20 12416G2 NYLON WEDGE LOCK CLAMP, 10" (NOT ILLUSTRATED)........................... AR
21
22
23
24 28083G01 BRAKE COMPENSATOR BUMPER ............................................................... 2
25 624690 BRAKE CABLE (DRIVER SIDE), 37.06" ........................................................ 1
26 624691 BRAKE CABLE (PASSENGER SIDE), 46.81" ............................................... 1
27
28 01111G01 RETAINING RING (SS), 13/32"....................................................................... 4
29
30 10386G3 CLEVIS PIN, 5/16" X 13/16" LG ...................................................................... 3
31 10387G3 COTTER PIN, 3/32" X 3/4" LG........................................................................ 3
BRAKES
