Page E-7
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
ELECTRICAL
81 00414G6 HEX HEAD BOLT, 1/4" - 20 X 3/4" LG............................................................. 2
82 00559G7 FLAT WASHER, 1/4” ....................................................................................... 2
83 14390G4 LOCK NUT, 1/4" - 20 ....................................................................................... 2
84
85
86 31539G1 NYLON CLAMP (NOT ILLUSTRATED)........................................................... A/R
87 657599 ACCESSORY HARNESS (NOT ILLUSTRATED)............................................ 1
88 634271 SOC JUMPER HARNESS (NOT ILLUSTRATED)........................................... 1
89 634272 REVERSE BUZZER JUMPER HARNESS (NOT ILLUSTRATED).................. 1
90
91
92
93 634277 JUMPER HARNESS, 12V POWER OUTLET ................................................. 1
94 71078G01 12V POWER OUTLET .................................................................................... 1
95 633988 HARNESS, 12V POWER OUTLET................................................................. 1
96 71055G01 RIVET, 3/16" DIA............................................................................................. 2
97
98
99
100 639384 USB PORT ...................................................................................................... 1
101 635865 USB HARNESS............................................................................................... 1
102 637381 JUMPER (YELLOW) ....................................................................................... 1
103 638233 ELECTRONICS BOX ...................................................................................... 1
104 670675G01 GPS DISPLAY UNIT, 7" (NOT ILLUSTRATED).............................................. 1
105 670675G02 GPS DISPLAY UNIT, 10" (NOT ILLUSTRATED)............................................ 1
106 664519G01 GPS DISPLAY UNIT, 7" (NOT ILLUSTRATED).............................................. 1
107 664519G02 GPS DISPLAY UNIT, 10" (NOT ILLUSTRATED)............................................ 1
108 637081G01 KEYSWITCH PLATE ....................................................................................... 1
109
