Page F-3
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
31 11027G2 FLANGED NUT, 1/4" - 20.......................................................................... 2
32 612711 SOLENOID, 48V (INCLUDES ITEMS 33 - 36) ......................................... 1
33 00544G4 LOCK NUT, 5/16" - 24 ........................................................................ 2
34 00565G8 LOCK WASHER, 5/16"....................................................................... 2
35 00565G5 LOCK WASHER, #10 ......................................................................... 2
36 00526G4 LOCK NUT, #10 - 32........................................................................... 2
37 73049G01 COVER............................................................................................................ 1
38 16469G1 FLAT FENDER WASHER, 1/4" ....................................................................... 1
39 00114G6 HEX WASHER HEAD BOLT, 1/4" - 14 X 3/4" LG............................................ 1
ELECTRONIC SPEED CONTROL
