Page G-3
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
FRONT SUSPENSION AND STEERING
1 652822 FRONT AXLE .................................................................................................. 1
2
3 70942G03 SPINDLE AND HUB ASSEMBLY, 4 LUG (PASSENGER SIDE)
(INCLUDES ITEMS 4 - 13).............................................................................. 1
4 70940G02 SPINDLE ASSEMBLY (PASSENGER SIDE)............................................ 1
5 25146G1 GREASE SEAL......................................................................................... 1
6 11750G2 ROLLER BEARING................................................................................... 2
7 70589G01 WHEEL HUB............................................................................................. 1
8 19862G1 LUG BOLT, 1/2" - 20 X 1 3/16" LG............................................................ 4
9 12093G1 CASTELLATED NUT, 1" - 14 .................................................................... 1
10 00798G8 COTTER PIN, 5/32" X 1 3/4" LG............................................................... 1
11 70648G01 FLANGED BEARING................................................................................ 1
12 70749G01 BEARING.................................................................................................. 1
13 51141G1 RACE BEARING....................................................................................... 2
14 70673G03 SPINDLE AND HUB ASSEMBLY, 4 LUG (DRIVER SIDE)
(INCLUDES ITEMS 5 - 13, 15)........................................................................ 1
15 70742G02 SPINDLE ASSEMBLY (DRIVER SIDE) .................................................... 1
16
17 602979 STEERING WHEEL......................................................................................... 1
18 607925 CLIPBOARD.................................................................................................... 1
19
20 14390G2 LOCK NUT, 5/8" - 18 ....................................................................................... 1
21 664789 WARNING LABEL (STEERING WHEEL)........................................................ 1
22
23 70876G02 TIE ROD ASSEMBLY (INCLUDES ITEMS 24 - 28) ........................................ 1
24 70897G02 THREADED ROD, 24" LG ........................................................................ 1
25 70902G01 TIE ROD END (LEFT HAND THREADS) ................................................. 1
26 01069G01 JAM NUT, M12 X 1.25 (LEFT HAND THREADS)..................................... 1
27 70902G02 TIE ROD END (RIGHT HAND THREADS)............................................... 1
28 01069G02 JAM NUT, M12 X 1.25 (RIGHT HAND THREADS)................................... 1
29 00734G1 LOCK NUT, 7/16" - 14 ..................................................................................... 2
30
