When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Page H-2
Service Parts Manual
MOTOR
1 624105 MOTOR 48V (INCLUDES ITEMS 2 - 10)........................................................ 1
2 625886 COMMUTATOR END HEAD .................................................................... 1
3 626171 ARMATURE.............................................................................................. 1
4 626172 FRAME AND FIELD ASSEMBLY ............................................................. 1
5 625884 BRUSH BOX ASSEMBLY ........................................................................ 1
6 73120G03 BRUSH SPRING ...................................................................................... 4
7 73120G25 BRUSH AND TERMINAL SERVICE KIT.................................................. 1
8 73120G06 RETAINING RING .................................................................................... 1
9 73120G07 BEARING ................................................................................................. 1
10 625885 COVER..................................................................................................... 1
11 73277G01 RETAINING RING, 1.66"................................................................................. 1
12 73328G01 SPEED SENSOR MAGNET ........................................................................... 1
13 01037G02 PAN HEAD TORX SCREW, #10-32 X 1/2" LG ............................................... 1
14 620422 SPEED SENSOR HARNESS ......................................................................... 1
15 24261G1 BUMPER SPLINE........................................................................................... 1
16 624109 O-RING, 1 1/2" O.D X 1 3/8" I.D...................................................................... 1
To Next Page
