Page L-3
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 *** FRONT SEAT BACK ASSEMBLY (INCLUDES ITEMS 2 - 7).......................... 1
71751G03 OYSTER
71751G02 GREY
71751G04 TAN
71751G05 SPECIAL
2 *** VINYL SEAT BACK COVER ..................................................................... 1
71753G03 OYSTER
71753G02 GREY
71753G04 TAN
71753G05 SPECIAL
3 * FLAT STAPLE ........................................................................................... A/R
4 71752G01 PLASTIC SEAT BACK COVER ................................................................ 1
5 645021 SEAT BACK BASE ................................................................................... 1
6 01107G01 PAN HEAD TORX SCREW (SS), #8 X 5/8" LG ........................................ 4
7 71754G01 FOAM PADDING (SEAT BACK) ............................................................... 1
8 71204G01 HEX HEAD BOLT, 1/4" - 20 X 7/8" LG............................................................ 4
9 11027G1 LOCK NUT, 5/16" - 18 ..................................................................................... 6
10 70113G01 ADJUSTABLE BUMPER ................................................................................. 4
11 00560G1 FLAT WASHER, 3/8" ....................................................................................... 4
12
13
14
15 70364G01 SPACER, 8.45" X 2" ........................................................................................ 2
16 625525 SEAT BACK SUPPORT .................................................................................. 2
17 00427G2 HEX HEAD BOLT, 3/8" - 16 X 1" LG................................................................ 4
18
19 *** FRONT SEAT BOTTOM ASSEMBLY (INCLUDES ITEMS 20 - 32) ................ 1
629269G0101 OYSTER
629269G0103 TAN
629269G0104 GREY
629269G0108 CUSTOM SOLID
20 615417 BUTTON HEAD TORX BOLT, M10 - 1.5 X 25MM LG .............................. 8
21 * FLAT STAPLE (SS), 3/8"........................................................................... A/R
22 * FLAT STAPLE .......................................................................................... A/R
23 71012G01 VINYL TRIM (SEAT BOTTOM) ................................................................. 1
SEATING - CONVERTIBLE CARRIER
