Page L-5
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
50 *** REAR SEAT BOTTOM ASSEMBLY
(INCLUDES ITEMS 20 - 25 AND 51 - 59) ....................................................... 1
74139G03 OYSTER
74139G04 TAN
74139G02 GREY
74139G05 SPECIAL
51 71702G01 HIP RESTRAINT (DRIVER SIDE) ............................................................ 1
52 71701G01 HIP RESTRAINT (PASSENGER SIDE).................................................... 1
53 76417G01 SEAT BOTTOM (WOOD).......................................................................... 1
54 00661G8 HEX HEAD BOLT, 1/4" - 20 X 1" LG ......................................................... 8
55 01110G01 FLAT WASHER, 1/4"................................................................................. 8
56 00664G7 LOCK WASHER, 1/4" ............................................................................... 8
57 17618G1 NYLON CLAMP (NOT ILLUSTRATED) .................................................... 1
58
59 74140G01 VINYL TRIM (SEAT BOTTOM) ................................................................. 1
SEATING - CONVERTIBLE CARRIER
