Page L-9
Service Parts Manual
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
26 614221 FLAT WASHER, 3/8" ....................................................................................... 24
27 00559G7 FLAT WASHER, 1/4" ....................................................................................... 4
28 11098G5 LOCK NUT (PLASTIC), 3/8" - 16..................................................................... 10
29 11027G5 FLANGED LOCK NUT, 3/8" - 16 ..................................................................... 4
30 14390G4 LOCK NUT (PLASTIC), 1/4" - 20..................................................................... 4
31 19853G1 SQUARE CAP TUBE, 1" ................................................................................. 2
32 01006G01 HEX HEAD BOLT, 3/8" - 16 X 1.25" LG........................................................... 4
33 71204G01 HEX HEAD BOLT, 1/4" - 20 X 7/8" LG............................................................. 8
34 634178 SEAT BACK SUPPORT .................................................................................. 1
35 634179 FOOTREST WELDMENT................................................................................ 1
36 634175 ARMREST (REAR SEAT)................................................................................ 2
37 634174 SEAT FRAME SUPPORT................................................................................ 2
38 634180 SEAT FRAME WELDMENT ............................................................................ 1
SEATING - CONVERTIBLE CARRIER
