Page P-3
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
REAR AXLE
653637 Service Parts Manual
32 639868 BALL BEARING (TMB202) ....................................................................... 2
33 639755 COUNTER SHAFT.................................................................................... 1
34 640744 BALL BEARING (6006)................................................................ 1
35 639758 GEAR,34................................................................................................... 1
36 639869 KNOCK PIPE ............................................................................................ 2
37 639760 BALL BEARING (6304)............................................................................. 2
38 639768 FLANGED HEX HEAD BOLT, M8 - 1.25 X 40MM LG............................... 1
39 639769 GEAR, 17.................................................................................................. 1
40 28689G01 COLLAR, 24 X 7.5MM .............................................................................. 1
41 639771 GEAR, 52.................................................................................................. 1
42 670697 CENTER SHAFT....................................................................................... 1
43 639774 CLUTCH PIN............................................................................................. 1
44 670696 GEAR, 61.................................................................................................. 1
45 639797 SPACER, 20 X 2MM ................................................................................. 2
46 639872 DIFFERENTIAL CASE (INCLUDES ITEMS 34, 47, 49 AND 50) ....... 1
47 639800 DIFFERENTIAL PAIR GEAR ....................................................... 1
48 26808G01 HEX HEAD BOLT, M10 - 1.25 X 26MM LG........................................ 6
49 28723G01 DIFFERENTIAL SHAFT............................................................... 1
50 28697G01 SPRING PIN, 4 X 40L.................................................................. 1
51 639801 BALL BEARING (6007)................................................................ 1
52 640739 GEAR, 60 COMPLETE (INCLUDES ITEM 51). ................................. 1
53 607938 CASTLE NUT, M22 - 1.5 .......................................................................... 2
54 639876 AXLE SHAFT L COMPLETE (INCLUDES ITEM 56) ................................ 1
55 639881 AXLE SHAFT R COMPLETE (INCLUDES ITEM 56)................................ 1
56 639836 BALL BEARING (6205DD) ................................................................. 2
57 607939 AXLE CASE L COMPLETE ...................................................................... 1
58 607940 AXLE CASE R COMPLETE...................................................................... 1
59 26814G01 SNAP RING, 52MM .................................................................................. 2
60 639839 FLANGED HEX HEAD BOLT, M8 - 1.25 X 60MM LG .............................. 9
61 639840 FLANGED HEX HEAD BOLT, M10 - 1.25 X 25MM LG ............................ 10
62 639844 SHIFT SHAFT COMPLETE ...................................................................... 1
To Next Page
