Page C-3
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
BODY
653637 Service Parts Manual
30 71055G01 RIVET (ALUMINUM), 3/16” X 1.118” LG
(FOR VEHICLES MANUFACTURED UNTIL MARCH 29, 2014) .................... 9
31 10570G11 RIVET (SS), 3/16" X .70" LG .......................................................................... 2
32
33
34 00438G6 HEX HEAD BOLT, 5/16" - 18 X 3/4" LG........................................................... 2
35 00571G2 FLAT WASHER, 5/16" ..................................................................................... 2
36
37 606405 E-Z-GO NAMEPLATE .................................................................................... 1
38 71597G01 SELF THREADING NUT, 5MM X 10MM X 15MM........................................... 2
39
40 628022 CENTER COMPARTMENT............................................................................. 1
41 625224 CENTER COMPARTMENT DIVIDER ............................................................. 1
42 658058 CENTER COMPARTMENT WITH USB .......................................................... 1
