Page C-9
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
BODY
653637 Service Parts Manual
28 71578G01 REAR BUMPER .............................................................................................. 1
29 00571G2 FLAT WASHER, 5/16" ..................................................................................... 4
30 71102G01 HEX HEAD BOLT, 1/4" - 20 X 3/4" LG............................................................. 4
31 71514G01 BUMPER PLUG .............................................................................................. 4
32 14601G17 RIVET (ALUMINUM), 3/16" X 9/16"................................................................. 4
33
34
35 615239 ROCKER PANEL WITH SILL PLATE (DRIVER SIDE).................................... 1
36 617333 ROCKER PANEL WITH SILL PLATE (PASSENGER SIDE) ........................... 1
37 15058G6 RIVET (ALUMINUM), 3/16" X 15/16"............................................................... 4
38
39
40
41
42
43 634161 HEXALOBULAR FLANGE BOLT, M6 - 1 X 34.5MM LG ................................. 4
44 23726G4 SPACER, 5/16"................................................................................................ 4
45 601476 LOCK NUT, M6 - 1........................................................................................... 4
46 625246 REAR REFLECTOR (RED) (PASSENGER SIDE) (NOT ILLUSTRATED)...... 1
47 625244 REAR REFLECTOR (RED) (DRIVER SIDE) (NOT ILLUSTRATED) .............. 1
48 627564 REAR REFLECTOR (RED) (PASSENGER SIDE) ......................................... 1
49 627563 REAR REFLECTOR (RED) (DRIVER SIDE) ................................................. 1
50
51 656538 SPLASHGUARD FRONT-KIT (INCLUDES ITEMS 52 - 54) ........................... 1
52 651127G01 SPLASH GUARD (DRIVER SIDE) ........................................................... 1
53 651127G02 SPLASH GUARD (PASSENGER SIDE) .................................................. 1
54 656649 SPLASHGUARD HARDWARE KIT (INCLUDES ITEM 55) ...................... 1
55 16816G1 RATCHET RIVET, .25" X .680"............................................................... 4
