Page D-3
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
BRAKES
653637 Service Parts Manual
31 10387G3 COTTER PIN, 3/32" X 3/4" LG........................................................................ 3
32
33
34 70601G01 KICK-OFF LINK............................................................................................... 1
35 17838G1 NYLON BUSHING........................................................................................... 2
36 20835G1 TEFLON WASHER, 3/8" ................................................................................. 2
37 00559G8 FLAT WASHER, 5/16" ..................................................................................... 2
38 10387G3 COTTER PIN, 3/32" X 3/4" LG........................................................................ 2
39 70098G01 KICK-OFF CAM PIVOT................................................................................... 1
40 10097G6 FLANGED BEARING ...................................................................................... 2
41 70587G01 KICK-OFF CAM, PARK BRAKE...................................................................... 1
42 71215G01 SET SCREW WITH PATCH LOCK, 1/4" - 20 X .5" LG ................................... 2
43 14134G4 SPACER, .76" O.D. X .395" I.D. X 1.25" LG.................................................... 1
44
45 70113G01 ADJUSTABLE BUMPER ................................................................................. 1
46 11027G1 LOCK NUT, 5/16" - 18 ..................................................................................... 1
47
48 70080G02 CATCH BRACKET........................................................................................... 1
49 00414G6 HEX HEAD BOLT, 1/4" - 20 X .25" LG............................................................. 2
50 14390G4 LOCK NUT (SS), 1/4" - 20............................................................................... 2
51 612558 COMPENSATOR ASSEMBLY (INCLUDES ITEMS 52 - 61) ........................... 1
52 00532G4 HEX NUT, 1/4" - 20 ................................................................................... 2
53 629486 SPHERICAL HEX NUT, 5/16"- 24............................................................. 1
54 28082G01 EQUALIZER BRACKET............................................................................ 1
55 15121G1 FLAT WASHER, 5/16"............................................................................... 2
56 17979G1 ACCELERATOR ROD BUSHING, .464" I.D. X 1" O.D. X 2" LG............... 1
57 23061G2 TUBE......................................................................................................... 1
58 23463G1 COMPRESSION SPRING ........................................................................ 1
59 652256 BRAKE YOKE........................................................................................... 1
60 11098G9 HEX LOCK NUT, 5/16" - 24 ...................................................................... 1
61 612557 COMPENSATOR ROD LINK .................................................................... 1
To Next Page
