VISUMATIC VOYAGER – Pocket - Binoculars
VISUMATIC VOYAGER – Pocket - Binoculars
3. Now cover the left front lens with your hand and rotate the right eyepiece until the image
is sharp.
4. The binoculars have now been adjusted to your eyes.
5. Rolling down the eyecups
• If you wear glasses, roll down the eyecups (C); this will reduce the distance between the
eyepiece and the eyes, providing an improved field of view.
6. Specifications
Type Roof
Field of view 5,6°, 98 m/1.000 m
Magnification 10 x 25 mm
Housing dimension 105 x 113 x 35 mm
Weight 184 g (device only)
Important information on product safety!
• Use a soft lens brush or a soft, lint free cloth to clean the binoculars.
• If you use a cleaning agent, never apply the liquid to any of the glass surface, but sprinkle it
on the cloth.
• Protect the instrument from damp, extreme temperatures, vibration or shock.
3. Adjusting the field of view
• The distance between the eyes varies from one person to the next. To achieve perfect align-
ment of the eyes and the lens openings, hold the binoculars in the normal viewing position
and move the two barrels either apart or closer to each other until you have a single, clear
field of view.
4. Focusing
1. Set the right eyepiece (A) to zero and look at a distant object.
2. Cover the right front lens with your hand and rotate the focusing wheel (B) until the
image in the left eyepiece appears sharp. Keep both eyes open while you make this
adjustment.
TFA_No. 43.1008_Anleitung 07.11.2019 13:14 Uhr Seite 5
