KIT CONTENTS
3
The parts in your kit:
30
44
411211
33
38
1
39
6
21
26
40
18
17
16
10
9
7
32 25
23
8
No. Description Count Item No.
1 Anchor pin 40 702527
2 Joint pin 12 702524
3 Shaft plug 30 702525
4 Shaft pin 2 702526
5 Axle lock 12 702813
6 Washer 12 703242
7 Long frame 4 703239
8 Short frame 6 703232
9 Long rod 6 703235
10 Short rod 6 703233
11 Long axle 4 703234
12 Medium axle 5 703238
13 Short axle 1 703236
14 Medium pulley wheel 4 702518
15 Small pulley wheel 4 702519
16 Large gear wheel (60 teeth) 2 702506
17 Medium gear wheel (40 teeth) 4 702505
18 Small gear wheel (20 teeth) 7 702504
19 Baseplate 2 703237
20 Crankshaft 2 702599
21 XL (extra long) axle 1 703518
22 Connector bridge 2 703231
23 Turbine blade 16 702815
43
24
36
35
29 37
14
15
28
19
13 31 22
4
20
42
5 3 2
No. Description Count Item No.
24 Rubber band (long) 1 703241
25 Rubber band (medium) 1 703374
26 Cotton cord (white) 1 703244
28 Wheel 2 703230
29 Tire ring (medium pulley wheel) 2 703251
30 Anchor pin lever 1 702590
(Part separator tool)
31 Crank 2 703377
32 Straw (red) 2 703513
33 Digging shovel 1 703514
34 Experiment book (not shown) 1 703510
35 Measuring cup 1 703532
36 Plastic strip for spring motor 1 703240
37 Film for cutouts 1 703380
38 Boat hull 1 703519
39 Die-cut cardboard sheets 1 703522
40 Hydraulic pump 1 703515
41 Hydraulic switch 1 703516
42 Hydraulic cylinder 4 703378
43 Narrow tubing 1 703500
44 Thick tubing 1 703511
