KIT CONTENTS
What’s inside your experiment kit:
Checklist:
No. Description Quantity Part No.
C Plastic frame C (Parts C1 – C29) 1 724 854
D Plastic frame D (Parts D1 – D26) 1 724855
E Plastic frame E (Par ts E1 – E17) 1 724 856
P1 Round metal rod, S 1 724859
P2 Round metal rod, M 4 724860
P3 Round metal rod, L 5 724859
P4 Round metal rod, XL 1 724859
No. Description Quantity Part No.
P5 Hexagonal metal rod, M 1 724859
P6 Hexagonal metal rod, L 1 724859
P7 Foam sticker sheet 1 724860
P8 Plastic spiral spring, large 1 724857
P9 Plastic spiral spring, small 1 724858
P10 Plastic storage bag 1 724860
These parts are shown
in actual size:
If you are missing any
parts, please contact
Thames & Kosmos
technical support.
Good to know!
