4
Hauptkomponenten • Main components
1 ... Filament-Führung • Filament tube
2 ... Extruder • Extruder
3 ... Hotend • Hotend
4 ... Beheizte Druckplatte • Heated printing plate
5 ... Basis • Base
a ... Heizelement • Heating element
b ... Hotendkühlung • Hotend cooling
c ... Werkstückkühlung • Fan for material cooling
d ... Druckdüse • Nozzle (ø 0,4 mm)
Zl
Zr
X
Y
1
2
3
4
5
b
a
c
d
Testdruck
Testprint
