— E5 —
Connection
Connecting the Microphone(s)
Microphones:
Connect a microphone into Mic jack 1
u
as well
as Mic jack 2
v
(when desired).
NOTE: Do not drop or tap the Mic as damage
to the Mic or speakers may occur. Do not twirl
the microphone cord as it will cause damage to
the encased wiring.
Connecting the Unit to a TV
HDMI Jack (Out)
HDMI Jack (In)
HDMI IN 1
HDMI Cable
Rear of External TV
To output the video, lyrics and
audio to your TV, perform the
following steps:
Plug the HDMI cable (not included)
into the HDMI Jack on the back of
the unit. Plug the other end of the
HDMI cable into the HDMI input
on your TV.
NOTES:
• This unit can be used with or without a TV, but it is highly recommended to use a TV in order
to utilize all the features.
• Also refer to the TV’s User Guide for input and display instructions.
• To see the lyrics on the screen, you must play MP4 or MP3+G files through the USB port.
v
u
To Next Page
