Thermal Dynamics ULTRA-CUT 100 User Manual

Manual No. 0-4819 3-29 INSTALLATION
Output Connections
1. Refer to the illustrations. Make the following output connections to the Arc Starter.
Pilot Lead
Connection Detail
Inner Shield
Connection Detail
Inner Shield Lead
Pilot Lead
Art # A-04933
Pilot Return Cable and Inner Shield Lead (from Torch Leads)
Art # A-04757
Coolant Return (Red)
from Torch
Coolant Supply
(Green) to Torch
Some items are removed
for clarity.
Coolant Supply Fitting
(Tagged with Green)
Coolant Return Fitting
(Tagged with Red)
Coolant Supply and Return Hoses (from Torch)
