Thermal Edge NE020 - Page 2

1751 Hurd Drive ● Irving, Texas 75038 ● (972) 580-0200 ● (888) 580-0202 ● Fax (972) 580-0277
URL: www.thermal-edge.com ● Email: support@thermal-edge.com
SP-ENG-210-000-06 Rev 2.2 2 | P a g e
Title: NE020, NE030, & NE040 Air Conditioner Technical Manual
Department: Engineering
Objective: To provide important information for maintenance, diagnostics and advance operations of the
Thermal Edge NE020, NE030 & NE040 Series Air Conditioners.
Revision History:
Rev
Date
Owner
Description of Changes
1.0
09-22-10
G. Gonzalez
New Format Initial Release
1.2
12-01-10
G. Gonzalez
Update Unit Specification Section for SCCR, Update Preliminary
Test Section and Controller Section for Heater Set point Defaults
1.3
12-05-11
G. Gonzalez
Update Schematic Section & specs for max ambient
1.4
03-05-12
B. Slotnick
Update filter media part number
1.5
01-14-13
B. Slotnick
Revise mounting procedure
1.6
02-22-13
B. Slotnick
Added power connector
1.7
08-17-13
B. Slotnick
Added Appendix A
1.8
01-15-14
B. Slotnick
Update Adjustable Temperature Probe length
1.9
04-03-14
B. Slotnick
Update email address
2.0
08-04-14
B. Slotnick
Delete Celsius programming flash drive key
2.1
01-22-15
B. Slotnick
Update system schematic
2.2
03-23-15
B. Slotnick
Parts list: Added high pressure switch; updated filter information
Statement of Confidentiality
The Manual and other materials contain proprietary information, comprising Thermal Edge Inc.'s trade secrets.
Please maintain the confidentiality of all proprietary information during and after the term of the use agreement.
Also, please refrain from using this proprietary information in any other manner, including in any other
business, without Thermal Edge Inc.’s written approval.
Thermal Edge Inc. reserves the right to revise and otherwise modify the Manual to reflect changes in the
requirements, standards, and operating recommendations. The Manual is the sole property of Thermal Edge
Inc. It must be returned upon the expiration or the termination of the term of use agreement.
By accepting the Manual you have read and understand the Statement of Confidentiality and will abide by its
terms and conditions.
