Thermal Solutions APEX APX425C - 13 Service Parts (continued); Jacket and Trim Components

146
106308-05 - 3/23
APEX Installation, Operating, & Service Instructions
Jacket and Trim Components
Key
No.
Description
Part Number
APX425C APX525C APX625C APX725C APX825C
5A Left Side Panel 106249-01 106249-02 106249-03 106249-04
5B Right Side Panel (includes rating label instructions) 106517-01 106517-02 106517-03 106517-04
5C Top Panel (includes gaskets) 106254-01 106254-02 106254-03 106254-04
5D Top Control Access Panel (includes label) 106518-01
5E Front Door (includes gaskets and labels) 106516-01 106516-02
5F
Replacement Door Latch Kit (includes latch, cam, and
hardware)
106509-01
5G Rear Panel (includes gaskets) 106253-01 106253-02 106253-03
5H Junction Box Access Panel, 5.5 in. x 10.5 in. 109175-01
5J Access Panel, 5 in. x 8 in. (includes gasket) 109176-01
5K Gas Train Support Bracket (includes U-bolt) 109185-01 109187-01 109188-01
5M Nylon Glide Replacement Kit 105014-01
5N
Vent Connector for CPVC/PP/SS (includes jacket
gasket and vent pipe gaskets)
4 in. (100 or 110 mm)
108866-01
6 in. (150 or 160 mm)
109227-01
5P Combustion Air Connector Gasket 109189-01
13 Service Parts (continued)
