8
106308-05 - 3/23
APEX Installation, Operating, & Service Instructions
Table 1-6: Ratings
Apex Series Gas-Fired Boilers
Model
Number
Input (MBH)
Gross
Output
(MBH)
Net Ratings
Water
1
(MBH)
Thermal
Efficiency (%)
Combustion
Efficiency (%)
Min. Max.
APX425C 80 399 375 326 94.1 94.5
APX525C 100 500 485 422 97.0 96.0
APX625C 125 625 594 517 95.0 96.0
APX725C 145 725 689 599 95.0 95.0
APX825C 160 800 760 661 95.0 94.0
Ratings shown are for installations at sea level and elevations up to 2,000 ft. at minimum vent length. For elevations
above 2,000 ft., see Appendix A Instructions for High Altitude Installations above 2,000 ft.
1
Net AHRI Water Ratings based on allowance of 1.15. Consult manufacturer before selecting boiler for installations
having unusual piping and pickup requirements, such as intermittent system operation, extensive piping systems,
etc.
A. Move boiler to approximate installed position.
B. Remove all crate fasteners.
C. Lift and remove outside container.
D. Remove boiler from cardboard positioning sleeve
on shipping skid.
E. Move boiler to its permanent location.
NOTICE: Do not drop boiler.
NOTICE: Due to the low water content of the
boiler, mis-sizing of the boiler with regard to the
heating system load will result in excessive boiler
cycling and accelerated component failure.
Thermal Solutions DOES NOT warrant failures
caused by mis-sized boiler applications. DO NOT
oversize the boiler to the system. Multiple boiler
installations greatly reduce the likelihood of boiler
oversizing.
1 Product Description, Specifications and Dimensional Data (continued)
2 Unpacking Boiler
WARNING
Explosion Hazard. Asphyxiation Hazard.
Electrical Shock Hazard.
•
Installation of this boiler should be undertaken
only by trained and skilled personnel from
a qualified service agency. Follow these
instructions exactly.
•
Improper installation, adjustment, service, or
maintenance can cause property damage,
personal injury or death.
!
3 Pre-Installation and Boiler Mounting
